Three Phase Pad Mounted Transformer

Description

The three phase pad mounted transformer supplies three-phase loads through an enclosed transformer installed on a concrete pad. The published primary-voltage range is 2.4–35 kV, with project configuration selected for industrial, commercial or residential underground distribution.

Three Phase Pad Mounted Transformer — Key Features

• Three-phase distribution arrangement.
• Ground-level installation on a prepared concrete pad.
• Locked steel cabinet encloses electrical connections.
• Separate access to connection compartments.
• Front access for inspection and servicing.

Technical Parameters

Standards

Technical specification reference: IEC 60076-1:2011 (general requirements for power transformers). The applicable requirements and test programme are to be agreed in the project specification.

Applications

• Industrial parks and factories.
• Commercial buildings.
• Residential communities.
• Underground distribution networks.
• Renewable-energy distribution installations.
